Ultrasonic Cleaner Model M 3 Manufacturers and Suppliers
An Ultrasonic Cleaner Model M-3 is a compact cleaning device that uses high-frequency sound waves (ultrasonics) in a liquid medium to remove dirt, grease, oil, oxidation, and other contaminants from objects without damaging their surfaces.
The cleaner works by generating ultrasonic sound waves through transducers fixed to the tank. These waves create microscopic cavitation bubbles in the cleaning solution. When the bubbles collapse, they produce micro-jet forces that loosen and lift contaminants from the surface—even in hard-to-reach crevices.
Key Application
- Pharmaceutical Industries – Ensures contamination-free cleaning of lab glassware and tools.
- Hospitals – Used for pre-sterilization cleaning of surgical and medical instruments.
- R&D Laboratories – Maintains precision by cleaning sensitive lab equipment.
- Jewellery – Restores shine by removing dirt, oil, and polishing residues.
- Specification
| Model | M-3 US |
|---|---|
| Tank Size | 240 * 140 * 100 mm (L*W*H) |
| Outer Size | 265 * 162 * 240 mm (L*W*H) |
| Tank | SS 304 |
| Enclosure | SS 304 |
| Tank Capacity | 3 Liter’s |
| Ultrasonic Power | 100 Watts |
| Heater Power | 100 Watts |
| Ultrasonic Frequency | 33 kHz ± 3 kHz |
| Timer | 0 to 15 Minutes (Digital Countdown Base) |
| Power Input | 230 Vac |
| Transducers | Imported make PZT type bonded at the bottom of the tank with weld bond technique. |
| Ultrasonic Generator | Advance latest MOSFET / IGBT based smps |
| Accessories | Lid, Basket, Powercord |
